Hobbywing Seaking V3 30a ESC Waterproof 30302060

Performance & Reliability

Built with high-quality components and coupled with cutting-edge firmware,
the Seaking 60A V3.1 is featured by unmatched performance and reliability.
Multiple safety adjustable options are in use,
with the implementation of the low-voltage cutoff protection,
thermal protection and throttle signal loss protection.

Efficient Cooling System

The Hobbywing patented heat-conductive copper bar cover on the power board of
the Seaking 60A V3.1 can efficiently and effectively transfer heat to the integrated CNC machined
billet aluminum water cooled heat sink housing thus keeping
your ESC as cool as possible.

Waterproof Design

100% waterproof without the need of extra protection.

Built-in BEC

The built-in switch mode BEC with a maximum output of 6Amp and
voltage of 6V make this ESC compatible with high voltage servo.

Special Algorithm Design

The special algorithm implemented in the ESC make the acceleration
more incredible and sailing more stable.

Separate PRG/FAN Port

The separate PRG/FAN port on the ESC can connect ESC to a program
box (via the trio-color programming cable) and start ESC programming.

Type

    Brushed/Brushless : BL
    Waterproof : WP

Specifications

    Cont./Peak Current : 30A/180A
    BEC Output : Linear Mode:6V/1A

Wires & Connectors

    Output Wires : Black-16AWG-75mm*3
    Input Connectors : No
    Output Connecotors : No
    Transmitter : Supported
    LED Program Box : Supported
    LCD Program Box : Not Supported
    WiFi Module : Not Supported
    Program Port : Program/Throttle Wire

Firmware

    Firmware Upgrade : Not Supported

Size & Weight

    Size : 54.5x28.3x18.7mm
    I.D./O.D. of the Water Cooling Pipe : Ф2.0/4.0 mm
    Weight : 41g

Applications

    Boat Length <45cm
